Driven Pile

Driven pile is one of the popular and oldest method where the piling is done by dropping the hammer which drives the casing pipe resting on a MS pile shoe up to the termination level. In this method piling can be done for a diameter ranging from 300mm to 600mm only. Once the pile is driven up to termination level, reinforcements is lowered and the casing pipe is filled with the concrete. Now the concrete is compacted by dropping of the hammer and simultaneously casing pipe is lifted fully. Care to be taken that the concrete is filled up to the required level. Here there are two types methods.

•  Cast-in situ pile
•  Pre- cast pile

Normally this is used as friction pile and wherever the depth is standard. We also use this method where there is a high chance of soil collapse. If the ground water pressure is more we prefer pre-cast pile method.

Except for the noise and the vibration it creates while driving, There are lot of advantages with driven pile technique, like we can save a lot of time by increasing the productivity. We will be able to access deeper depths also. We have the best team, which manages our skilled labours to extract exceptional results in the site. We always finish our projects on time with quality, way before the deadline and thus save money, time etc for our clients. Hence our clients always prefer us in the market. Contact us to know more!
